Mercury DSP 8.4 HD
MERCURY DSP 8.4 HD (Digital Sound Processor) Subwoofer Box with 4 Channel Amplifier
✅ 8" Subwoofer Box
✅ 4 Channel Amplifier Buildin
✅ Bluetooth Steaming with Mobile Phone
✅ Remote Monitor
✅ Digital Sound Processor
Function Introduction
Specification
Active Range:≥110dB
S/N Ratio : ≥100dB
T.H.D. : ≤0.05%
Freq. Response : 20Hz～20KHz
Input Impedance : Low level input:20KΩ, High level input:240Ω
Low Level Output : 100Ω
Power Output (4Ω) : RMS 50W X 4，Peak Power 400W X 1
Signal Input / Output Range : RCA Input：3.3Vpp；High level：30Vpp；RCA Output：13.0Vpp
Temperature : -10～70℃
Supply Voltage : DC 9V～15V
Turn-On REM Output : +12V starting voltage output (0.1A)
Power Consumption : ≤0.1W
Weight : 4.6kg
Dimension : 345Lx245Wx70H mm
Function
Input Signal Type : Choice: 4 ch high level, 2 ch stereo low level,Blue Tooth ，SQ play
RCA Output Location : Freely definable output sound position and speaker type
Output Signal Gain : Gain range: Mute, -59dB to 0dB
Output Signal Equalizer : 1-4 Each output channel 10 band , 5-6 each output channel is independent of the 8 band equalizer engine:
1. Equalizer type: 1st equalizer for Q and low pass option.
: 2nd equalizer for Q and high pass option
: others for Q balance
2. Frequency range: 20Hz～20KHz，resolution 1Hz
3. Q (slope or gradient): 0.404～28.85，resolution 0.01
4. Gain: -12.0dB～+12.0dB，resolution 0.1dB
Output Signal Crossover : Each output with 2 rank’’s high/low pass indepandent filter
1. Professional filter type: Butterworth, Linkwitz-Riley, Bessel
2. Filter crossover: 20Hz - 20KHz , Resolution 1Hz
3. Filter slope setting: CH1-CH4 6/12dB/Oct, CH5-CH66/12/18/24dB/Oct。
Output Phase And Time Delay : Each output channel can be adjusted for phase and timedelay, parameter
range
Phase: 0゜/180゜
Time delay: 0.000-5.4ms，0.00-187.00cm，0.00-74.00inch
Scene Operations : Unit can keep 6-style of music scenes by preset.
