6.5″ high end midwoofer with GZ-design aluminum cast basket offering unique ventilation
Model | High-quality SQ midwoofer |
---|---|
Diameter | 165 mm / 6.5″ |
Power handling (RMS/max.) | 140 / 200 Watts |
Impedance | 4 Ohms |
Efficiency | 89 dB |
Frequency Response | 40 Hz – 5000 Hz |
Voice coil | 38 mm / 1.5″ |
Cone | Aluminum-ceramics |
Mounting Ø | 144 mm / 5.67″ |
Mounting depth | 70 mm / 2.76″ |
Resonance frequency (Fs) | 38 Hz |
1.1″ high end silk dome tweeter with polished stainless steel housing
Model | High-End Tweeter |
---|---|
Diameter | 28 mm / 1.10″ |
Power handling (RMS/max.) | 100 / 150 Watts |
Impedance | 4 Ohms |
Efficiency | 90 dB |
Frequency Response | 2000 Hz – 30 kHz |
Cone | 2 layer coated silk |
Mounting Ø | 48 mm / 1.89″ |
Mounting depth | 35 mm / 1.38″ |
Resonance frequency (Fs) |
770 Hz
|
