Mercury C480

FEATURE ․Class AB Hi-end amplifier ․Up to 16V power & 8V audio input ․Mosfet power supply ․Bass boost ․LPF & HPF filter ․2 ohm stable circuits ․Double layers pcb ․Gain control SPECIFICATIONS Model C 480 Supply voltage 11~15V DC Power output @ 4 ohm 80W x 4ch Power output @ 2 ohm 120W x 4ch Bridge output @ 4 ohm 240W x 2ch Frequency response (±3dB) 10H~45kHz Signal to noise ratio >95dB Sensitivity 170mV~8V T.H.D. <0.1% Subsonic 10~60Hz Hi pass freq. 50Hz~3KHz Low pass freq. 50Hz~250Hz Bass boost 0~18 dB Bass boost EQ 32~100Hz Recommended fuse type 30Ax2 Dimensions (LxWxH) 241x158x51 mm

#mercuryaudio #mirageaudioสำนักงานใหญ่ #MirageRatchapreuk

Mercury C800

FEATURE ․Class D mono-block amplifier ․Up to 16V power & 8V audio input ․Mosfet power supply ․Bass boost & subsonic filter ․24dB/oct low pass filter ․1 ohm stable circuits ․Remote level control ․Double layers pcb ․Phase shift SPECIFICATIONS Model C 800 Supply voltage 11~15V DC Power output @ 2 ohm 500W x 1ch Power output @ 1 ohm 800W x 1ch Frequency response (±3dB) 10Hz~300Hz Signal to noise ratio >80dB Phase shift 0~180゜ Sensitivity 100mV~4V T.H.D. <0.1% Low pass freq. 32~300Hz Subsonic 10~60Hz Bass boost 0~12dB Bass bosst EQ 32~100Hz Recommended fuse type 40Ax2 Dimension (LxWxH) 241x158x51 mm

#mercuryaudio #mirageaudioสำนักงานใหญ่ #MirageRatchapreuk

Mercury R62 Limited

การันตี..คุณภาพเสียง ✨ แบบไม่ต้องลุ้น voucher

#mercuryaudio #mirageaudioสำนักงานใหญ่ #MirageRatchapreuk

Mercury R10

ปลดล็อกมิติแห่งเสียงเบส พร้อม "ปฎิวัติ" คุณภาพเสียงที่ทรงพลัง

#mercuryaudio #mirageaudioสำนักงานใหญ่ #MirageRatchapreuk

GROUND ZERO GZPW REFERENCE 250 : REFERENCE SERIES

GZPW Reference 250 High End 25 cm / 10" Subwoofer with linearized and Klippel-optimized high power motor - Resonance free cast basker - 3-Layer sandwich cone - Double layer BIMAX® spider - 50 mm / 2" Copper voice coil with 2 x 2 Ohm - Designed for smallest enclosures

#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk

GROUND ZERO GZMW REFERENCE 180 : REFERENCE SERIES

GZMW Reference 180 18 cm / 7.09" Kick / Midwoofer - 3.9 Ohm - 150 W - 7.09” Kick / Midwoofer with coated, pressed paper cone and linearised motor - Handmade machined aluminum basket - Rubber surrounds and connex spiders - Speakers optimized with the Ground Zero owned Klippel® system - Handmade in Europe and selected in pairs

#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk

GROUND ZERO GZPM REFERENCE 80 : REFERENCE SERIES

GZPM Reference 80 8 cm / 3.15" Midrange - 4 Ohm - 120 W - 3.15” Kick / Midwoofer with coated, double pressed paper cone and linearised motor - Handmade machined aluminium basket - Rubber surrounds and connex spiders - Speakers optimized with the Ground Zero owned Klippel® system - Handmade in Europe and selected in pairs

#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk

GROUND ZERO GZPT REFERENCE 28 : REFERENCE SERIES

GZPT Reference 28 2,8 cm / 1.1" Tweeter - 4 Ohm - 100 W - Handmade in Germany and selected in pairs - High power 1.1” aluminium/copper voice coil - Silkdome with special 2 layer coating - Polished alu housing with coupled rear chamber

#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk

GROUND ZERO GZDSP 6-8X

GZDSP 6-8X - Digital sound processor - Simple handling via 1-page user interface - Realtime setup (all functions) - Cirrus Logic single core 32 Bit, 8-channel, 192 kHz - 6 channel input / 8 channel output - High-level and low-level input - DC Auto-On (using the high-level input) - TOSLINK input (optical @12 ~ 96 kHz ) - 3.5mm stereo jack AUX – input connector - 6 x 31 band equalizer ( -18 to + 12 dB / Q: 0.5 - 9 ) 20 - 20000 Hz (on output A - F) - 2 x 11 band equalizer ( -18 to + 12 dB / Q: 0.5 - 9 ) 20 - 200 Hz (on output G/H) - Time alignment – adjustable range 0 - 15 ms / 0 - 510 cm - Adjustable filters (Butterworth) HPF / LPF / BPF with a slope of 6 – 48 dB/Oct. - selectable phase shift for each channel (0˚ or 180°) - Memory for up to 10 user presets - Optional remote control unit with LED display to adjust the main volume and switch between the presets and input mode

#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk

GROUND ZERO GZDSP 4-8X

GZDSP 4-8X Processor เชื่อมต่อกับ Bluetooth Stick สามารถจูนผ่านมือถือได้ 8-channel digital signal processor 8-channel DSP Digital signal processor with four channel high-level or RCA input, USB connection, remote control and auto-on function 8-channel digital signal processor High-level and line input Realtime setting 2x 28 bit Analog Devices processor Windows GUI software Separate 10 band equalizer for each channel Time delay Variable crossover Phase correction Automatic turn-on function Model 8-channel digital signal processor High Resolution Compatibel no TOSLINK Input no AUX Connector no High-Level Audio Mix up to 4 channels Input Sensitivity 0.5 – 1 V (RCA), 2 – 8 V (high-level) Adapter for Apple® devices no Remote included, included Dimensions (W x L x H) 168 x 114 x 27 mm / 6.61 x 4.49 x 1.06"

#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk

GROUND ZERO GZUB 800XACTII

GZUB 800XACTII ซับวูฟเฟอร์บ๊อกซ์ ขนาด 8" Ground Zero จากเยอรมัน 20 cm / 8″ high quality flat active subwoofer 180 Watts max 8″ flat active subwoofer with aluminum cast enclosure and integrated amplifier with high level input 8″ high quality flat active subwoofer enclosure Incl. remote control 120/180 Watts amplifier Aluminum cast housing High level input Automatic turn-on function Low pass filter Phase correction Incl. wiring kit Model Active Subwoofer Box Diameter 20 cm / 8" Amplifier Power (RMS/max.) 120 / 180 Watts Version Underseat mounting Frequency Response 34 – 100 Hz Low Pass Filter 50 – 100 Hz Phase switch 0° / 180° Enclosure Aluminium

#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk

GROUND ZERO GZRC 165AL-IV

GZRC 165AL-IV ลำโพง Ground Zero 3Ohm จากเยอรมัน เพื่อพลังเสียงเหนือระดับ 165 mm / 6.5″ 2-way component speaker system 190 Watts max 6.5″ 2-way component speaker system with aluminum cone and 3-ohms inpedance 2-way component speaker system Aluminum cone Rubber surround Nomex spider Resonance free steel basket High efficient 3 ohms version GZRT 25T Ferrite motor Separated high pass and low pass filter Incl. protection grill Model 2-way component speakers Durchmesser 165 mm / 6.5" Belastbarkeit (RMS/max.) 120 / 190 Watts Impedanz 3 Ohms Effizienz 89 dB Frequency Response 35 Hz – 26 kHz Tweeter GZRT 25T Midwoofer GZRK 16AL Einbautiefe 68 mm Frequenzweiche 2x HP / 2x LP Übergangsfrequenz 3500 Hz
