DESCRIPTION

  SPECIFICATION

TEST  CONDITION

1

 VOICE COIL（IMP）

4 W ±20%

AT(20°C) 3500  HZ  1  V

2

(DCR)

3.4W ±7%

3

OPERATION

MUST BENORMAL

PROGRAM SOURCE     10  W

4

BUZZES & RATTLES

MUST BENORMAL

SINE WAVE +2.2uF 6.3V 20-20KHz

5

RESPONSE FREQ fo

1300 ± 20%   HZ

WITHOUT  BAFFLE

6

OUT-PUT S-P-L

88 ± 3dB  MEAM VALUE ATKHZ

  AT 1m/1W 4K/6K/8K/10K/15KHZ

7

FREQ RESPONSE

Fo  ～  20KHZ

-10dB   OVDER

20dB  MAX (1m /1W)

8

RATED POWER INPUT

          10    W

9

 MAX POWER INPUT

   W

10

 DISTORTION

%    MAX

RATED POWER INPUT HZ

11

TOTAL FLUX

GAUSS

   ±15%

12

 MAGNET

( ¢24.5*3.5 mm  NdFeB)

MATERAL WEIGHT (0.16 Oz)

/  gr

   DESCRIPTION

  SPECIFICATION

 TEST  CONDITION

1

VOICE COIL（IMP）

4 W ±20%

AT(20°C) 3500  HZ  1  V

2

(DCR）

3.6W ±7%

3

OPERATION

MUST BENORMAL

PROGRAM SOURCE     10  W

4

BUZZES & RATTLES

MUST BENORMAL

SINE WAVE +3.3uF 6.3V 20-20KHz

5

RESPONSE FREQ fo

1300 ± 20%   HZ

WITHOUT  BAFFLE

6

OUT-PUT S-P-L

88 ± 3dB  MEAM VALUE ATKHZ

  AT 1m/1W 4K/6K/8K/10K/15KHZ

7

FREQ RESPONSE

Fo  ～  20KHZ

-10dB   OVDER

20dB  MAX (1m /1W)

8

RATED POWER INPUT

          10    W

9

MAX POWER INPUT

   W

10

DISTORTION

%   MAX

RATED POWER INPUT HZ

11

TOTAL FLUX

GAUSS

   ±15%

12

MAGNET (主)

( ¢19.5*3 mm  NdFeB)

MATERAL WEIGHT (0.16 Oz)

/  gr
