GROUND ZERO GZCS 200MBR-LHD

GZCS 200MBR-LHD Car specific 200 mm / 8″ woofer 90 Watts max Car specific 200 mm / 8″ woofer for left hand drive Mercedes 8″ car specific woofer Right hand drive vehicles / passenger´s side Pressed paper-fiber cone Resonance free steel basket Neodymium motor Car specific connection 1 piece / package

#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk

AUDISON PRIMA AP 8.9 BIT

Audison Prima AP 8.9 BIT The AP8.9 bit amplifier was designed by Audison R&D Department to achieve maximum sound quality in OEM Integration applications. The powerful management software proves the ability to acquire the bit Drive presets which the Audison team fine-tuned specifically for your car. Thanks to the innovative power supply stage, a power of 520 W total can be achieved in an extremely compact case. The non-amplifiable ninth channel can be used to drive a subwoofer via the mono AP1 D amplifier. Power Output Load Imp. 8 Channels 4 Channels (bridge) 4 Ohm 35 W x 8 130 W x 4 2 Ohm 65 W x 8

#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk

AUDISON BIT ONE

Audison BIT ONE Despite its compact size, the bit One is equipped with a fast, latest generation 266 MHz / 32 bit floating point DSP microprocessor, working in real time on all the functions of the most complete systems. Managed and configured by a simple and intuitive computer software, it is possible to make adjustments to improve the signal through each phase of its path; from input to output. Eight input channels for four different signal typologies (amplified, pre-amplified, coaxial electric and TOSLINK optical digital) and six different sources managed through a remote control, making the bit One a unique interface suitable for any need. Eight analog and/or digital output channels ensure vastexpandability for any audio system configuration.

#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk

AUDISON PRIMA APK 163

Audison APK 163 Prima 3 way System 165 mm (6.5") Woofer 100 mm (4") Midbass 26 mm (1") Tweeter 46,5 x 37,5 x 20,1 mm (1.83" x 1.47" x 0.8") APCX TW Crossover 72 x 44,5 x 23 mm (2.83" x 1.8" x 0.9") APCX MD Crossover 72 x 44,5 x 23 mm (2.83" x 1.8" x 0.9") APCX WF Crossover Power Handling 125 W Continuous Power375 W Peak Power Impedance 4 ΩFrequency Response 50 - 20k Hz Sensitivity 93,5 dB/Spl

#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk

AUDISON PRIMA APK 165

Audison Prima APK 165 16.5 cm/6.5 Inch, 2 Way, komposet Impedance: 4 Ohms, 142 mm, depth: 56 mm diameter, pack of 2. 93.5 dB SPL - 2 x 100/300 W RMS/max. frequency 60-20.000 Hz, High quality membrane, large storage basket schwingspulendurchmesser plat High qualité-souple with flat hochtonpegelanpassung 26 mm in height Comp 2 way System SystemSize 165 mm (6.5") Woofer26 mm (1") Tweeter46,5 x 37,5 x 20,1 mm (1.83" x 1.47 x 0.8) CrossoverPower Handling 100 W Continuous Power300 W Peak PowerImpedance 4 Ω Frequency Response 60 - 20k Hz Sensitivity 93,5 dB/Spl

#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk

AUDISON BIT ONE HD

Audison BIT ONE HD 13-CHANNELS HI-RESOLUTION DIGITAL SIGNAL PROCESSOR Analog Devices DSP (ADSP-21489), 32 bit floating-point Sharc series (450 MHz clock) Audison Full DA HD chain, providing pure digital signal tranfer preserving all the information of the Hi-Res audio file reproduced. 8 + 1 digital channels with crossover FIR filters. 5 poles input equalization (MASTER and AUX) FIR type bit One HD features 8 memories bit One HD to the Audison bit Tune through an automatic procedure, all the processor’s basic audio parameters

#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk

AUDISON APX6.5

APX 6.5 APX 6.5 features a concentric coaxial tweeter: with one single point of sound emission it is possible to obtain a consistent in-phase response, with consequent reconstruction of the acoustic scene comparable to a system of separate woofer + tweeter. The 6.5″ cones surround features the exclusive shallow “Triple Wave” profile, for maximum excursion linearity. CompTwo way coaxial

#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk

AUDISON AP1

AP 1 The AP 1 tweeter features a 26 mm diameter emission diaphragm, an acoustic lens designed to compensate for the frequency response within the 10kHz – 13kHz range, a Neodymium REN magnet and extremely small sized dedicated passive crossover

#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk

AUDISON APX4

APX 4 APX 4 features a concentric coaxial tweeter: with one single point of sound emission it is possible to obtain a consistent in-phase response, with consequent reconstruction of the acoustic scene comparable to a system of separate woofer + tweeter. The 4″ cones surround features the exclusive shallow “Triple Wave” profile, for maximum excursion linearity.

#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk

AUDISON APBX 10DS NO AMP

APBX 10 DS The APBX 10 DS, a 10” subwoofer loaded in a 12-litres sealed enclosure, is the line’s “flagship”. It is dedicated to the highest performing Prima systems, using the AP1 D amplifier for the sub section. The speaker’s mechanical excursion of more than 18 mm provides for incredible authority, while the refined Thiele&Small parameters set-up provides the ideal balance for all music genres.

#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk

AUDISON APBX 10 AS2

APBX 10 AS2 ACTIVE SUB BOX The Prima APBX 10 AS2 active subwoofer, with 10-inch driver,features a dedicated high performance amplification module which enhances all the passive box technologies, such as the 2S² (2 Sides / 2 Sounds) design, the Plug & Play terminal block and ultra-compact size. The amplification module, with power outputs of 400W RMS is developed with he-li technology (high efficiency / low impedance), which thanks to the absence of the DC-DC voltage booster reaches the impressive 90% efficiency level, very close to the theoretical limit of the D-Class. New input stage DBT (Dynamic Bass Tracking) technology allows 100% use of the he-li (High Efficiency Low Impedance) amplifier power and to enjoy a tense and dynamic bass even at very high listening volumes. Eliminating the voltage booster was made possible thanks to the development of the new dual coil drivers, which inherit all the technological background of the Prima subwoofers, but differ for the ultra low impedance (0.16 ohms for APBX 10 AS). This feature ensures a perfect synergy with the he-li (High Efficiency Low Impedance) technology, maximizing the combination of amplifier, speakers and sealed box, to obtain low, powerful and crisp frequencies. The controls section is complete and provides an optimal regulation of the low frequency emission in the car cabin. The Butterworth low pass filter at 12dB/Oct. with variable cut-off frequency (50-200 Hz) can be bypassed, when used with an AP bit processor with pre-out output dedicated to the sub. The adjustable bass-boost control (0 ÷ 6 dB) at 45 Hz allows the user to emphasize the response in the lower side of the spectrum. The high-level speaker-in input on multi-pole connector eases the integration with OEM audio systems while the low-level input on RCA is dedicated to the connection with after market sources. The subwoofer automatic turn on/off function ART (Automatic Remote Turn-On) can be configured to be controlled by the source’s remote signal, by the voltage variation on the high-level input or by the audio signal on both inputs. Phase control (0 – 180 °) completes the equipment. The SSP (Sub Smart Plug) terminal block is provided with a single Plug&Play connector to be able to disconnect the box easily and safely.

#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk

AUDISON APK 165P

APK 165P The new Prima APK 165P two-way loudspeaker system, capable of handling up to 345 W peak, is the ideal combination to fully exploit the power of the AP F8.9 bit or all other Prima amplifiers used in high power configurations. The exclusive AIF technology (Any Install Faceplate) of the AP 1P Tweeter provides the installer with 3 different faceplates for total application versatility and a significant reduction in installation time. The woofer has been designed to perform at its best in OEM placements, combining excellent power handling and efficiency.
