GZPF 40SQ 40 mm / 1.6″ high end full range speaker Description 80 Watts max 1.5″ high end full range speaker with aluminum cone 40 mm / 1.6″ high end full range speaker Made in Germany Anodized aluminum cone Aluminum cast housing Neodymium motor Gold plated soldering terminal 1 pair / wooden box Additional Information Model High end full range speaker Diameter 40 mm / 1.6" Belastbarkeit (RMS/max.) 50 / 80 Watts Impedanz 4 Ohms Effizienz 84 dB Frequency Response 500 Hz – 24 kHz Voice coil 16 mm / 0.63" Cone anodized aluminum Einbautiefe 39 mm Resonance frequency (Fs) 400 Hz
#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk
ชุดลำโพง Ground Zero Reference 3 ทาง Gold Edition Limited งาน Handmade Germany ทั้งชุดประกอบไปด้วย 1. GZPT Reference 28 Gold Edition (Tweeter) GZPT Reference 28 Gold Edition 28 mm / 1.1″ high end tweeter – Gold Edition 150 Watts max 1.1″ high end silk dome tweeter with CNC turned and gold plated aluminum housing 25 mm / 1″ high end tweeter Made in Germany Double coated silk dome High power capable copper voice coil Gold plated aluminum housing Damped coupled chamber Wave diffuser Neodymium motor Gold plated screw terminal 1 pair / wooden box --------------------------------------------------- 2. GZPM Reference 80 (Midrange) GZPM Reference 80 80 mm / 3.15″ high end midrange speaker 120 Watts max 3.15″ high end midrange speaker with coated paper cone 80 mm / 3.15″ high end midrange speaker Made in Europe Coated and double pressed paper cone Conex spider Hand made basket with CNC milled parts Linearized motor India rubber surround Incl. protection grill Gold plated soldering terminal 1 pair / wooden box 3.GZMW Reference 180 180 mm high end midwoofer 150 Watts max 180 mm high end midrange speaker with coated paper cone 7″ high end midwoofer Made in Europe 25 mm / 1″ voice coil Conex spider Hand made basket with CNC milled parts Linearized motor Incl. protection grill Gold plated soldering terminal 1 pair / wooden box
#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk
GZRC 165.3SQ 165mm 2-Way Component Speaker-System Description 3-Way Sound Quality speaker system with variable crossover frequency, 3 ohm impedance and 25mm silk dome tweeter High quality 3-way SQ component system Klippel® optimized midwoofer with aluminum cone Nomex spider / rubber surround Copper cap for impedance linearizing Resonance free steel basket 3.15” SQ midrange with aluminum cone Neodymium motor / compound basket 1″ SQ silk dome tweeter with mounting accessories Vented neodymium motor 12 dB/oct. crossover with level adjustment (not for ACT version) 230 watt max. / 150 watt rms 3 Ohms Highlights Mehr Leistung am Verstärker / Radio durch 3 Ohm Technologie Variable Mittelton-Trennfrequenz (High/Low) Sehr hoher Wirkungsgrad (90dB) Großer Seidenkalottenhochtöner (25mm) für feinste Details und klaren Sound Anspruchsvoller 80mm Mitteltöner mit Neodym-Antrieb und Aluminiummembrane Leistungsstarker Tieftöner mit Aluminium-Membrane Technische Daten Durchmesser 165 mm Belastbarkeit (rms/max.) 150 / 230 Watt Impedanz 3 Ohm Wirkungsgrad 90 dB Frequenzgang 35 Hz – 25 kHz Hochtöner GZRT 25SQ Mitteltöner GZRM 80SQ Tieftonlautsprecher GZRK 16SQ Einbautiefe 68 mm Übergangsfrequenz Hochtöner 4600 Hz Übergangsfrequenz Mitelltöner 200 Hz
#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk
GZRC 165.2SQ 165mm 2-Way Component Speaker-System Description Sound Quality speaker system with variable crossover frequency, 3 ohm impedance and 25mm silk dome tweeter Klippel® optimized midwoofer with aluminum cone Nomex spider / rubber surround Copper cap for impedance linearizing Resonance free steel basket Gold-plated terminals 1″ SQ silk dome tweeter with mounting accessories 12 dB/oct. crossover with level adjustment (not for ACT version) 190 watt max. / 120 watt rms 3 Ohms Highlights Mehr Leistung am Verstärker / Radio durch 3 Ohm Technologie Variable Hochtöner Trennfrequenz (High/Low) Sehr hoher Wirkungsgrad (90dB) Großer Seidenkalottenhochtöner (25mm) für feinste Details und klaren Sound Leistungsstarker Tieftöner mit Aluminium-Membrane Technische Daten Durchmesser 165 mm Belastbarkeit (rms/max.) 120 / 190 Watt Impedanz 3 Ohm Wirkungsgrad 90 dB Frequenzgang 35 Hz – 25 kHz Hochtöner GZRT 25SQ Tief-/Mitteltonlautsprecher GZRK 16SQ Einbautiefe 68 mm Übergangsfrequenz 4600 Hz (Hi)
#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk
GZDSP 6-8X PRO 8-channel digital signal processor 8-channel DSP Digital signal processor with six channel high-level or RCA input, USB connection, digital and AUX input as well as auto-on function 8-channel digital signal processor High-level and line input Realtime setting 32 bit Cirrus Logic Prozessor Windows GUI software Separate 31 band equalizer for each channel Time delay Variable crossover Phase correction Automatic turn-on function for the high level input Model 8-channel digital signal processor High resolution compatible yes TOSLINK & Coaxial Input 24-bit / 12 -192 kHz AUX Anschluss 3.5 mm socket High-Level Audio Mix up to 6 channels Frequency Response 5 Hz – 20 kHz (-3 dB) Signal-to-Noise > 110 dB Eingangsempfindlichkeit 3 – 15 V (Hochpegel) Max. Output 4 V RMS, 4 V RMS Adapter for Apple® devices optional Remote Control optional Preset Memory 10, 10 Dimensions (b x l x h) 185 x 151 x 42 mm
#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk
GZHA MINI FOUR 4-channel class D compact amplifier 640 Watts 4-channel amplifier with high efficient class D circuit, integrated activ crossover and compact dimensions Compact sized 4-channel amplifier SMD components Class D technology Variable active crossover and bass boost, phase shift Stabilized power supply Large terminals Solid heatsink with engraved Ground Zero lettering High-level input with auto-on function Model Class D compact amplifier Channels 4 Output Power (@ 4Ω) 4x 80Watts RMS Output Power (@ 2Ω) 4x 130 Watts RMS max. Output Power 640 Watts Frequency Response 5 Hz – 38 kHz HPF / LPF / BPF ● / ● / ● Bass Boost / Phasenregelung ○ / ○ High-Level Input / Auto-on ● / ● Remote Control ○ BIAS Setting ○ Linkmode ○ Dimensions (b x l x h) 135 x 210 x 52 mm
#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk
GZHA MINI ONE 1-channel class D compact amplifier 750 Watts 1-channel subwoofer amplifier with high efficient class D circuit, integrated activ crossover and compact dimensions Compact sized mono amplifier SMD components Class D technology Variable active crossover and bass boost, phase shift Link mode (for two amplifiers) Stabilized power supply Large terminals Solid heatsink with engraved Ground Zero lettering Bass remote control included High-level input with auto-on function Model Class D compact amplifier Channels 1 Output Power (@ 4Ω) 220 Watts RMS Output Power (@ 2Ω) 390 Watts RMS Output Power (@ 1Ω) 630 Watts RMS max. Output Power 750 Watts Frequency Response 10 – 250 Hz, 10 – 250 Hz HPF / LPF / BPF ● / ● / ● Bass Boost / Phasenregelung ● / ● High-Level Input / Auto-on ● / ● Remote Control ● BIAS Setting ○ Linkmode ● Dimensions (b x l x h) 135 x 210 x 52 mm
#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk
GZRA MICRO FOUR 4-channel class D compact amplifier 500 Watts 2-channel amplifier with high efficient class D circuit, integrated active crossover and compact dimensions Very compact 4-channel amplifier SMD components Class D technology Active crossover Efficient power supply Plug-in connector Space-saving heatsink with Ground Zero lettering High-level input with auto-on function Model Class D compact amplifier Channels 4 Output Power (@ 4Ω) 4x 60Watts RMS Output Power (@ 2Ω) 4x 100 Watts RMS max. Output Power 2x 250 Watts Frequency Response 5 Hz – 25 kHz HPF / LPF / BPF ● / ● / ○ Bass Boost / Phasenregelung ○ / ○ High-Level Input / Auto-on ● / ● Remote Control ○ BIAS Setting ○ Linkmode ○ Äquiv. Luftvolumen (Vas) 75 x 190 x 44 mm
#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk
GZDSP 4.80AMP 4-channel amplifier with 8-channel DSP 8-channel DSP 4-channel amplifier with integrated 8-channel DSP, four channel high-level or RCA input, USB connection, digital and AUX input as well as auto-on function 8-channel digital signal processor High-level and line input Realtime setting 32 bit Cirrus Logic Prozessor Windows GUI software Separate 31 band equalizer for each channel Time delay Variable crossover Phase correction Automatic turn-on function for the high level input Model 4-channel amplifier with digital signal processor High resolution compatible yes TOSLINK input 24-bit / 12-96 kHz AUX Anschluss 3.5 mm socket High-Level Audio Mix up to 6 channels Frequency Response 20 Hz – 20 kHz (-3 dB) Signal-to-Noise > 100 dB Eingangsempfindlichkeit 2 – 15 V (high-level) Output power 4x 80 Watts RMS @ 4 Ohm Remote Control optionally Preset Memory 10, 10 Dimensions (b x l x h) 185 x 215 x 42 mm
#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk
GZPC 16.3SQ 165 mm / 6.5″ 3-way component speaker system 300 Watts max 6.5″ high end 3-way component speaker system with aluminum cast basket including 1.1″ silk dome tweeters 3-way component speaker Made in Germany Alumium-ceramics cone Conex spider Solid aluminum cast basket Universal 4 ohms version GZPT 28SX GZPM 80SQX-II High end 18 dB/oct and 12 dB/oct crossover 1 kit / package Model 3-way component speakers Durchmesser 165 mm / 6.5" Belastbarkeit (RMS/max.) 200 / 300 Watts Impedanz 3 Ohms Effizienz 90 dB Frequency Response 30 Hz – 30 kHz Tweeter GZPT 28SX Mitteltonlautsprecher GZPM 80SQX-II Midwoofer GZPK 16SQ Einbautiefe 68 mm Frequenzweiche GZPX 16.3SQ Übergangsfrequenz 200/3000 Hz
#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk
GZPA 4SQ (Plutonium Series) 4-channel high performance SQ amplifier 1400 Watts 4-channel high end amplifier with integrated activ crossover, BIAS adjustment and high quality parts for dedicated music lovers High-End 4-channel SQ amplifier MOSFET technology Variable active crossover with bypass function Variable BIAS setting High quality components Solid terminals Efficient heatsink with illuminated Ground Zero lettering Fulfilling High Resolution audio demands Model 4-channel high-performance SQ amplifier Channels 4 Output Power (@ 4Ω) 4x 125 Watts RMS Output Power (@ 2Ω) 4x 225 Watts RMS Output Power (@ 1Ω) 4x 350 Watts RMS max. Output 2x 840 Watts Frequency Response 10 Hz – 50 kHz HPF / LPF / BPF ● / ● / ● Bass Boost / Phase Shift ● / ○ High-Level Input / Auto-on ○ / ○ Remote ○ BIAS Setting ● Linkmode ○ Dimensions (W x L x H) 222 x 420 x 60.5 mm / 8.74 x 16.54 x 2.38"
#mirageaudioสำนักงานใหญ่ #MirageRatchapreuk
GZPA 2SQ (Plutonium Series) 2-channel high performance SQ amplifier 1000 Watts 2-channel high end amplifier with integrated activ crossover, BIAS adjustment and high quality parts for dedicated music lovers High-End 2-channel SQ amplifier MOSFET technology Variable active crossover and bass boost, phase shift Variable BIAS setting High quality components Solid terminals Efficient heatsink with illuminated Ground Zero lettering Fulfilling High Resolution audio demands Model High-Performance SQ amplifier Channels 2 Output Power (@ 4Ω) 2x 175 Watts RMS Output Power (@ 2Ω) 2x 315 Watts RMS Output Power (@ 1Ω) 2x 500 Watts RMS max. Output 1200 Watts Frequency Response 10 Hz – 50 kHz HPF / LPF / BPF ● / ● / ● Bass Boost / Phase Shift ● / ● High-Level Input / Auto-on ○ / ○ Remote ○ BIAS Setting ● Linkmode ○ Dimensions (W x L x H) 222 x 420 x 60.5 mm / 8.74 x 16.54 x 2.38"
